Container GFS - K2

Container-type fuel filling station, K2 type is a filling station with a ground tank designed to store and dispense oil products on the territories of transport companies, farms and construction sites, inaccessible areas, in mountain areas or in areas with harsh climatic conditions (low and high temperature or large temperature differences). It can be performed for use in automatic, semi-automatic and usual (without automation) modes and can be transported by road and rail way transport.

CFFS, K2 type has: lightweight metal frame performance; small required space; design allowing to use CFFS in urban environments.

For safe CFFS operation in automatic (cold) mode, the product is equipped with the following systems:

• two-walled tank for the mineral oils storage (1 to 4 types) having total capacity of up to 40 cub. m equipped with a set of technologic equipment;
• oil products delivery system;
• filling station dispenser;
• vehicles identification system;
• explosion proof external and internal lighting system using light sensor;
• technologic compartment;
• tank filling system equipped with an electric pump;
• automatic fire-fighting system;
• tanker truck grounding device;
• electronic continuous oil products level control system;
• ventilation system;
• CCTV equipped with motion sensors and video recorder;
• alarm system controlled on-line;
• tank shell condition control system;
• ambient air condition control system;
• 2 operators’ GSM transmitter, radio, and Wi-Fi communication; and
• software for the monitoring of the condition of all the aggregates and container filling station with the on-line data transfer to filling stations network dispatcher and warning on working parameters going beyond the permissible limits.

It is also possible to equip CFFS for operation in semi-automatic mode - the operator controls oil products parameters and storage conditions and in manual mode (without automation) - the operator controls all parameters of oil products storage and delivery.

Environmental control system

Tank shells control system

Truch tank grounding device

Tank filling system with electric pump
